Wall Mounted Water Butt (100 Litres)

Wall Mounted Water Butt - Description

• Wall Mounted Water Butt Kit
• The Original Prestige Water Butt
• Capacity: 100 Litres (22 Gallons)
• Slimline Design
• Material: Made From Recycled Plastic
• Colour Options
  • Black
  • Slate Grey
• Dimensions (HxWxD): 122 x 46 x 23cm (Approx. 48 x 18 x 9 Inches)
• Works With Both Square & Round Down Pipes
• Fits All Round or Square Down Pipes (Up to 80mm Diameter)
• Note: Installation instructions Available Under Downloads Tab

Delivery - Important Note - Please Read

• We can only deliver orders of this product by Fastway couriers
• Please do not choose DPD as your courier for orders containing this item

Wall Mounted Water Butt - Contents

• 1x Wall mounted water butt
• 1x Wall bracket
• 6x Screws & Wallplugs
• 1x Tap bung (Factory fitted)
• 2x Top caps (Factory fitted)
• 1x Installation instruction sheet

Wall Mounted Water Butt - Features

• Space saving
• Neat & tidy - No messy diverter
• Tap can be fitted either side of water butt (Limits bending to fill watering can)
• Automatically fill and divert excess water
• Several units can be linked together (See our water butt linking kit)
• Includes central support to ensure water butt maintains shape & structure
• Bung in base of tank to allow you clear & clean out tank after some years

Wall Mounted Water Butt - Uses

• Perfect for the garden
• This 100 litre water butt is ideal for saving rain water & money whilst helping the environment
• Allows you to supply soft water to your plants

Wall Mounted Water Butt - Advantages

• Clever wall mounted water butt
• Designed to compliment and fit any style of house
• Prestige water butt is a complete kit
• Sturdy & easy to install
• Totally child safe & pet proof
• Provides superior strength and durability
• Resistance to weathering

Wall Mounted Water Butt - How to Install

• Follow these instructions carefully
• All brackets and fixings must be used correctly
• Use the correct sized drill bit and appropriate screwdriver head with the fixings provided

• Step 1: Decide Height
  • Decide on the height & position you wish to fix the water butt, allowing enough room for your watering can under the tap
  • The suggested height is 380mm (15") off ground level. At this point mark a level line on the wall (A)
• Step 2: Bottom Pipe Clips
  • The bottom pipe clip must be 125mm (5") below the water butt. Reposition if necessary
• Step 3: Outlet Section Cuts
  • Measure 1075mm (42 1/2") up from height line (A) and cut horizontally through the pipe
  • Now mark 140mm (5 1/2") above this cut and once again cut and remove this section (Section C)
• Step 4: Top Pipe Clips
  • Ensure that any top clip is positioned at a minimum of 240mm (9 1/2") above the top of the reservoir for ease of fitting
• Step 5: Fixing Wall Bracket
  • Taking the metal wall brackets, sit level with line (A)
  • The brackets must be separated horizontally by 220mm (9") to centres, symmetrical around the downpipe
  • The brackets will sit on the grooves on the underside of the water butt
  • Mark the holes, drill & fix the brackets to the wall with the screws and plugs provided
• Step 6: Fitting the Water Butt
  • Offer up the water butt to the top down pipe sliding it inside the centre hole of the water butt until it will go no further
  • With the water butt against the lower wall, lower it onto the bottom pipe section
  • Now with the water butt seated level and evenly on the brackets, mark the position dead centre of the two top holes and REMOVE THE WATER BUTT* to allow for drilling
  • Drill two holes. Insert the plugs. Offer up the water butt. Screw in the screws. Do not over-tighten

*Failure to do this may result in damage to the top area of the reservoir when using the drill

**Note: Leaves & debris can build up after some years. There is a bung outlet in the base of the tank to allow you to remove buildup

***If there are Deviations from the Assembly Instructions, Warranty will be voided, Please see attached

Also, Some customers place some mesh over the inlet to prevent leaves entering
